CM-40 Glue Cartoning Machine
40-60 cartons per minute — robust cartoning for diverse packet sizes.
Key Specifications
Full Technical Specifications
CM-40 Glue Cartoning Machine -- Complete specification details
| Specification | Value |
|---|---|
| Output Speed | 32-35 cartons per minute |
| Carton Type | Pre-cut mono cartons (200-220 GSM) |
| Length Range | 250–520 mm |
| Width Range | 65–125 mm |
| Height Range | 45–60 mm |
| Power Requirement | 2.5 kW |
| Air Consumption | 0.1 m³/min @ 5-6 bar |
| Machine Dimensions | 2100 × 1350 × 1800 mm |
| Weight | Approx. 850 kg |
Features & Benefits
Vacuum-assisted carton extraction and precise pulling rollers prevent feed jams
High-precision gum applicator applies adhesive to side tuckers for secure sealing
Servo-synchronized folding sequence ensures uniform pack geometry
Continuous operation with packet-push mechanism minimizes mechanical stress
Compact 2.1 x 1.35 m footprint integrates easily into existing packaging lines
This Machine Is for You If...
You need high-speed product cartoning for General Industrial production
You're upgrading from manual processes to automated fmcg packaging
You need a machine that delivers vacuum-assisted carton extraction and precise pulling rollers prevent feed jams
